Ultra Clear Silicone Rubber for Goggles


Product Description
This LIM3630 series silicone rubber from SQUARE is an ultra clear, high performance liquid silicone rubber made from a two-component system and catalyzed by platinum. It is suitable for injection molding of diving goggles.

The two-component silicone complies with the standards of USA FDA CFR 21.Part.177.2600, EN14350 for volatile compound and RoHS. After mixed in the prescribed amounts, the two components can be safely operated for 5 days under sealing condition and at 20℃. The rise of temperature will shorten the time.

Extremely high transparency
Excellent elastic resilience
Superb thermal stability and weather resistance (-60℃~250℃)
Anti heat aging

Main Application
The platinum cure silicone rubber is mainly used to making swimming goggles and other products that show high requirement for transparency.

20kg/pail or 200kg/pail

Typical Properties of the Silicone Rubber
Physical properties Test method Unit LIM3630-30A/B LIM3630-50A/B
Appearance (color) Visual test Transparent Transparent
Viscosity DIN53019 mPa.s A: (5.0 ~ 6.0)×104 A: (5.3 ~ 6.0)×104
B: (4.5 ~ 5.5)×104 B: (3.1 ~ 4.5)×104
SHORE Hardness D2204 A 28 ~ 32 48 ~ 52
Tensile strength D412 MPa ≥2.5 > 4.5
Elongation at Break D412 % ≥150 > 300
Tear strength D624B KN/m ≥7.0 ≥12
Resilience % ≥65 > 44
Tension set D412 DIE C % ≤3.0 < 2

1) Store the silicone rubber at room temperature in an indoor dry and ventilated place and keep it out of direct sunlight. Shelf life is 12 months.
2) Typical properties shown in the table are only for reference use. For specific molding process, please contact us directly.
